Appendix A — Printer Specifications
38 MP Compact4 Mark III User Guide
Technical Specifications
Embedded Fonts and Bar Codes
The printer is equipped with the most popular industry fonts and bar codes; see
the Class Series 2 Programmer’s Manual for full listings and detailed
information.
MP Compact4 and MP Compact4 Mobile Specifications
Mechanical
Width 230 mm (9.1”)
Depth 260 mm (10.2”)
Height 105 mm (4.1”); Compact4
125 mm (4.9”); Compact4 Mobile
Weight 3.5 kg (7.7 lbs.); Compact4
4.5 kg (9.9 lbs.); Compact4 Mobile
Operating temperature 5° C to 40° C (41° F to 104° F)
Humidity 10% − 95% non-condensing
AC input voltage 90 – 264 VAC, 47-63 Hz; Compact4
DC input voltage 24 – 48 VDC; Compact4 Mobile
Printing
Print method Direct thermal
Print speed 50 – 125 mm/s (2 – 4.9 IPS)
Resolution 8 or 12 dots/mm (200 or 300 dpi)
Tear bar Tear up
DRAM memory 64 MB
FLASH memory 128 MB
Ribbon/Media
Media types Roll-fed, die-cut, continuous, fan-fold
Width media range 40 – 115 mm (1.58” – 4.5")
Max. print width 115 mm (4.1”)
Print length minimum 10 mm (0.39")
Media thickness range 58 – 180 µm (0.0023 – 0.0071")
Media supply roll capacity 100 mm (3.9") O.D. on a 40 – 77 mm (1.5" - 3.0") core; Compact4
100 mm (3.9") O.D. on a 40 mm (1.5") core; Compact4 Mobile
Communications
Interface USB, RS-232 (RJ-45), and 10/100 BaseT LAN interface
Baud speed 300 to 115,000 bits per second (BPS)
Handshaking Xon/Xoff, CTS, DTR
Parity Even, odd or none
Stop bits 1 or 2
Data bits 7 or 8
