Operation Instruction VARIODYN
®
D1 Comprio
8 FB 798666.HO.GB0 / 07.13
Example of function key assignment
Circuit 1
Pre-selection of circuit 1 (button with toggle function)
Selects circuit 1 (or multiple circuits, if programmed), which can be used as the target of an
announcement.
Circuit 2
Pre-selection of circuit 2 (button with toggle function)
As described above, except circuit 2
Announcement
Announcement / speak (keep button held pressed)
Starts an announcement to the preselected circuits. If a gong has been programmed as an
attention signal for the announcement, it is only possible to speak after this signal has
finished.
Musik
on / off
Music on / off (button with toggle function)
Switches the background music on/off. The music can be played from an external CD player
or other audio source (via the available audio inputs of the DCS, UIM or via digital audio data
of the SCU).
Intercom
DCS 2
Intercom DCS 2: (keep button held pressed)
Establishes an intercom connection to another terminal. Communication takes place using the
microphone and built-in speaker.
Fire
announcement
Fire announcement (button with toggle function)
Pressing the button starts a previously saved fire announcement for the assigned loudspeaker
circuits (areas).
Toggle function Press once = ON Press again = OFF
Detailed information on this topic can be found in the Commissioning Instruction
(Part No. 798667.HO.GB0).
The button labelling can be created on a project-specific basis. The labels are laid in the button
recesses and held in place with the covers.
