Hoover HL5 PUSH&LIFT User Manual

P10
4. CLEANER MAINTENANCE
4.5 CLEARING A BLOCKAGE
FLOOR NOZZLE:
1. Remove the brushbar to visually identify any obstructions and remove them.
2. Thoroughly clean underneath the comb area to remove excess dust and debris.
3. Visualy check the nozzle neck for any blockages and remove them.
OTHER COMPONENTS & ACCESSORIES:
Remove the hose, handle, wand, crevice tool and mini turbo nozzle from
your product.
Vigorously shake the hose and visually check all components for any
obstructions and remove them.
11
2
3
STEP 3: Lift the brushbar
end latch to release the
brushbar and remove
from the nozzle.
STEP 1: Slide the nozzle
window slider to release
the nozzle window.
STEP 2: Remove the nozzle
window and place aside.
STEP 4: Remove the
brushbar from nozzle and
remove any excess debris.
STEP 5: Ret the brushbar
to the nozzle.
IMPORTANT: IF THE NOZZLE WINDOW IS NOT RE-ASSEMBLED CORRECTLY, THE BRUSHBAR STATUS LIGHT WILL FLASH RED WHEN THE PRODUCT IS SWITCHED ON.
4. CLEANER MAINTENANCE
4.4 BRUSHBAR
Thanks to ANTI-TWIST, your new Hoover upright vacuum features an integrated comb which helps to prevent hair wrapping around
the brushbar. However, if your cleaner is not picking up eciently, or brushbar status light is red, your brushbar may need to be
cleaned.
2
STEP 6: Ret the nozzle
window. Locate the front
edge rst then ‘click’ into
position at the back to
ensure location.
CLICKCLICK
