20
LUBRICATION
The motor and brushroll are equipped with bearings which contain sufficient lubrication for their
lifetime. The addition of lubricant could cause damage. Do not add lubricant to motor or brushroll.
Removing Brushroll
CAUTION
TO REDUCE THE RISK OF INJURY FROM MOVING PARTS: REMOVE BATTERY BEFORE SERVICING.
1
Slide orange tabs toward center.
2
Slide rear tab back, into
unlock position.
3
Remove bottom plate.
4
Pivot Brushroll out then
remove worn or broken belt,
and replace. Make sure belt is
centered on motor shaft and
sits properly within brushroll
grooves before placing back
into unit.
