Card reader board
Description Spare part number
Card reader board (includes cable) 747129-001
Before removing the card reader board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 49), and then remove the following components:
●
Service door (see
Service door on page 55)
●
WLAN module (see
WLAN module on page 58)
●
Top cover (see
Top cover/keyboard on page 61)
●
System board (see
System board on page 83)
Remove the card reader board:
1. Position the system board upside down.
2. Disconnect the cable from the system board (1).
3. Remove the two Phillips PM2.5×4.0 screws (2) that secure the card reader board to the system board.
Component replacement procedures 99
