Display assembly
This section describes removing the display assembly in its entirety and disassembling all the display
subcomponents.
If you only need to remove the display bezel, webcam/microphone module, or display panel, you do not need
to remove the entire display assembly from the computer. See
Display subcomponents (bezel, webcam,
panel) on page 50 for more information about removing the display subcomponents that do not require that
you remove the entire display assembly from the computer.
Description Spare part number
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in black HP 15 models 747121-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in white HP 15 models 747122-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in red HP models 747123-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in gray Compaq 15 models 747124-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in blue HP 15 models 750199-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in purple HP 15 models 750200-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in blue Compaq 15 models 750201-001
Display assembly (39.6-cm [15.6-in] HD, anti-glare, touchscreen, for use in purple Compaq 15 models 750202-001
Raw display panel for use in HP 15 and Compaq 15 models 747131-001
Raw display panel for use in HP 250 models and HP 255 models 749020-001
Antennas (includes wireless antenna cables and transceivers) 747107-001
Display bezel for use in HP 15 models 747113-001
Display bezel for use in Compaq 15 models 747114-001
Display cable (includes display panel cable and webcam/microphone cable) 747115-001
Display enclosure for use in black HP 15 and Compaq 15 models 747108-001
Display enclosure for use in white HP 15 and Compaq 15 models 747109-001
Display enclosure for use in red HP 15 and Compaq 15 models 747110-001
Display enclosure for use in gray HP 15 and Compaq 15 models 747111-001
Display enclosure for use in blue HP 15 and Compaq 15 models 750197-001
Display enclosure for use in purple HP 15 and Compaq 15 models 750198-001
Display enclosure for use in black HP 250 and HP 255 models 749015-001
Hinges (left and right) 747120-001
Webcam/microphone module 747144-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
70 Chapter 4 Removal and replacement procedures
