HP 245 G4 User Manual

Bottom
Component Description
(1) Battery lock Locks the battery in the battery bay.
(2) Battery bay Holds the battery.
(3) Battery release latch Releases the battery.
(4) Memory card reader Reads optional memory cards that enable you to store,
manage, share or access information.
To insert a card:
1. Hold the card label-side up, with connectors facing
the computer.
2. Insert the card into the memory card reader, and
then press in on the card until it is rmly seated.
To remove a card:
14 Chapter 2 External component identication

HP 245 G4 Specifications

General

Storage	128GB SSD
Display	1366 x 768
Graphics	AMD Radeon R4 Graphics
Operating System	Windows 10 Home
Battery	41 Wh Li-ion
Wireless	802.11b/g/n
Ports	2 x USB 2.0, 1 x HDMI, 1 x RJ-45, 1 x headphone/microphone combo
