Connecting the power cord
When connecting the power supply, it is important to follow the steps below to ensure the power supply cord
does not pull free from the computer.
1. Plug the female end of the power cord into the AC adapter (1).
2. Connect the other end of the power cord to an AC outlet (2).
3. Connect the round end of the power supply cord to the power connector on the rear of the computer (3).
4. Route the power supply cord through the retainer clip to prevent the cord from becoming disconnected
from the computer (4).
5. Bundle any excess power supply cord with the supplied strap (5).
IMPORTANT: Failure to secure the power supply cord with the retainer clip may result in the power supply
cord becoming disconnected and loss of data.
Connecting the power cord 5
