To remove the ClickPad TouchPad button board, follow these steps:
1. Remove the 2 screws that secure the ClickPad TouchPad button board to the top cover (1).
2. Lift up and remove the ClickPad TouchPad button board (2).
Reverse this procedure to install the ClickPad TouchPad button board.
Speaker assembly
Description Spare part number
Speakers (include cables) 635313-001
Before removing the speaker assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation mode,
turn on the computer, and then shut it down using the operating system.
2. Disconnect all of the external devices that are connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 32).
5. Remove the service cover (see
Hard drive on page 33).
6. Remove the hard drive (see
Hard drive on page 33).
7. Remove the keyboard (see
Keyboard on page 43).
8. Remove the top cover (see
Top cover on page 45).
Remove the speaker assembly:
ENWW Component replacement procedures 49
