Reverse this procedure to install the RJ-45 connector cover.
RJ-45 connector
Description Spare part number
RJ-45 connector (includes cable) 636452-001
Before removing the RJ-45 connector, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation mode,
turn on the computer, and then shut it down using the operating system.
2. Disconnect all of the external devices that are connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 32).
5. Remove the following components:
a. Service cover (see
Hard drive on page 33).
b. Hard drive (see
Hard drive on page 33).
c. Keyboard (see
Keyboard on page 43).
d. Top cover (see
Top cover on page 45).
e. Display assembly (see
Display assembly on page 51).
f. System board (see
System board on page 55).
Remove the RJ-45 connector:
To remove the RJ-45 connector, follow these steps:
1. Remove the 2 screws that secure the RJ-45 connector to the base enclosure (1).
2. Lift up and remove the RJ-45 connector (2).
62 Chapter 4 Removal and replacement procedures ENWW
