Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket or hard drive
connector adapter. The hard drive bracket and hard drive connector adapter are included in
the Hard Drive Hardware Kit, spare part number 758048-001. See
Mass storage devices on page 33
for more information on the Hard Drive Hardware Kit.
Description Spare part number
1-TB, 5400-rpm, SATA, 9.5-mm hard drive for use on all computer models 676521-001
750-GB, 5400-rpm, SATA, 9.5-mm hard drive for use on all computer models 634250-001
500-GB, 7200-rpm, SATA, 7.0-mm hard drive for use only on computer models equipped with an
Intel processor
678101-001
500-GB, 5400-rpm, SATA, 7.0-mm hard drive for use on all computer models 683802-001
Before removing the battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 52).
5. Remove the service cover (see
Service cover on page 53).
Remove the hard drive:
1. Release the zero insertion force (ZIF) connector (1) to which the hard drive connector cable is
attached, and then disconnect the hard drive connector cable (2) from the system board.
54 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
