TM 11-6625-1614-15
Section V
Paragraphs 5-16 to 5-19
Table 5-5
Model 410C
g.
5-16.
c. Adjust dc power supply to provide system
voltmeter reading of 1.50 v.
e. Model 410C should read approximately
150 ma.
This will verify a R
in
of approxi-
mately 0.3 ohms, where
R
410C
=E
total
-
R
X
I
410C
I
410C
f. Set Model 410C RANGE to 1.5 µa.
Replace Rx with a 9 K ohm ±1% resistor
Part No. 0730-0026).
h. Adjust dc power supply to provide system
voltmeter reading of 13.5 mv.
j.
Model 410C should read approximately 1.5
µa. This will verify R
in
of 9 K on 1.5 µa
range.
OHMMETER OPERATION.
a. A 10 ohm ±l% resistor Part No. 0727-
0335) and a 10M resistor Part No. 0730-
0168) will be required for this test.
b. Set Model 410C FUNCTION SELECTOR to
OHMS; RANGE to RX10.
c. Set pointer to using rear panel adjust-
ment (OHMS ADJ) if required.
h. If both of these ranges function properly, it
can be assumed that the remainder will also .
If meter does not function properly, refer to
Paragraph 5-31 for adjustment procedure.
5-17. AMPLIFIER OPERATION.
Deleted
see paras 5-19 and 5-24
d. Connect COM and DCA OHMS cables across
10 ohm resistor.
5-19. AMPLIFIER GAIN CHECK.
e. Meter should read 1 (±5%), indicating 10
ohms.
f. Reset Model 410C RANGE to RX10M. Re-
place 10 ohm resistor with 10 M ohm resistor.
g. Meter should read 1 (+5%), indicating 10 M
ohms.
Table 5-5. DC Voltage
a. Connect Voltmeter
Calibrator Model
738BR) output to Model 410C DCV and
COM
cables.
b. Connect DC Voltmeter Model
3440A/
3442A) to DC AMPLIFIER OUTPUT on rear
panel of Model 410C. Set DC Voltmeter RANGE
to 10 v.
Output Test
Deleted
5-4
Change
1
01556-2
