2-16 Removal and Replacement HP Omnibook 6000/6100
Figure 2-12. Unplugging the Keyboard Cables
Reassembly Notes
• Lay the keyboard face down on the top case slightly forward of its normal position, then reconnect
the keyboard and pointing stick flex cables.
• Slip the metal tabs on the bottom of the keyboard into their slots in the top case, then lower the
keyboard into place.
Caution
Do not excessively bend or fold the keyboard cables.
Keyboard and pointing
stick flex cables
To Next Page
