Page #7 background imageLoading...
Page #7 background image
| 7
The only indicator of battery failure is the failure of the switch internal clock to keep the correct time across a
reboot or power cycle. If a battery failure occurs, contact your authorized Aruba representative for assistance.
Batteries are not customer-serviceable and battery failures should be referred only to service personnel
authorized by Aruba.
For important safety, environmental, and regulatory information, see Safety and Compliance Information for
Server, Storage, Power, Networking, and Rack Products, available at http://www.hpe.com/support/Safety-
Compliance-EnterpriseProducts.
ATTENTION ll y a danger d'explosion s'il y a remplacement incorrect de la batterie.
Remplacer uniquement avec une batterie du même type ou d'un type équivalent
recommandé par le constructeur.Mettre au rebut les batteries usagées conformément
aux instructions du fabricant.
ATTENTION The battery supplied with this product may contain perchlorate material. Special handling
may apply in California and certain other states. See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate Web site for more information.
A risk of explosion exists if a battery is replaced by an incorrect type. Dispose of used batteries according
to the instructions.
Electrical Characteristics
Aruba 6300M PoE Switches (JL659A, JL660A, JL661A, JL662A,
R8S89A, R8S90A, R8S91A)
Power supply
n AC voltage
n Maximum current
n Frequency range
n Maximum power
JL670A
n 110V - 120V
n 11A
n 50-60 Hz
n 1050W Max
JL670A
n 200V/208V - 240V
n 9A/8A
n 50-60 Hz
n 1600W Max
Power supply
n AC voltage
n Maximum current
n Frequency range
n Maximum power
JL086A
n 100V - 240V
n 8A-3.5A
n 50-60 Hz
n 680W Max
JL087A
n 110V - 240V
n 12A-5A
n 50-60 Hz
n 1050W Max
Power supply
n DC input range (nominal)
n DC input range (maximum)
n Maximum current
n Maximum Power
JL758A
n -48V to -60V
n -36V to -72V
n 32A
n 1050W Max
