HP Compaq Business Notebook nc8000 User Manual

5–42 Maintenance and Service Guide
Removal and Replacement Procedures
5.21 TouchPad
✎
The TouchPad and bracket are included with the top cover, spare
part number 345061-001.
1. Prepare the notebook for disassembly (refer to Section 5.3)
and remove the following components:
❏ Keyboard (refer to Section 5.9)
❏ LED switch cover (refer to Section 5.15)
❏ Display assembly (refer to Section 5.18)
❏ Top cover (refer to Section 5.19)
❏ Speaker (refer to Section 5.20)
2. Remove the three Torx T8M2.0×3.5 screws 1 that secure
the TouchPad and bracket to the top cover.
3. Lift the left side of the bracket 2, then slide the bracket to
the left.
Removing the TouchPad Bracket
