Product Description
Maintenance and Service Guide 1–19
Table 1-4
Front and Right-Side Components
Item Component Function
1 Stereo speakers (2) Produce stereo sound.
2 Display release latch Opens the notebook.
3 Mute button Mutes the system volume. The button lights
up when volume is muted.
4 Volume control
buttons
Increase and decrease system volume.
Press the volume up button (on right) to
increase sound. Press the volume down
button (on left) to decrease sound.
5 PC Card eject buttons Eject an optional PC Card or smart card
(if a smart card reader is installed) from the
top or bottom PC Card slot.
6 Audio line-out jack Connects optional powered stereo
speakers, headphones, headset, or
television audio.
7 Microphone jack Connects an optional monaural
microphone.
8 PC Card slots Support optional Type I, Type II, or Type III
32-bit (CardBus) or 16-bit PC Cards.
✎
In select notebooks, one PC Card
slot can be replaced with a
factory-installed smart card
reader.
9 Secure Digital (SD)
slot
Accepts SD Memory Card and
MultiMedia Cards.
10 MultiBay Supports an optional MultiBay device, such
as a drive or battery pack.
11 Infrared port Provides wireless communication between
the notebook and an optional
IrDA-compliant device.
12 RJ-11 jack Connects a modem cable.
