Memory module
Description Spare part number
2048-MB memory module (667-MHz, DDR2) 616750-001
1024-MB memory module (667-MHz, DDR2) 616749-001
Before removing the memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 38).
5. Remove the service cover (see
Service cover on page 40).
Remove the memory module:
1. Using a small Phillips screwdriver, loosen the 2 memory module shield screws.
Component replacement procedures
51
