Reference Guide B–1
B
Technical Specifications
✎
All performance specifications are provided by the component
manufacturers. Performance specifications represent the highest
specification of all HP’s component manufacturers’ typical level
specifications for performance and actual performance may vary
either higher or lower.
5500/15” Series Monitor
Screen Size 15” (38 cm) visual diagonal
Viewable screen size 13.8” (35 cm)
Dot Pitch 0.28 mm (Diagonal)
Display Area Default 199 x 265 (mm) typical
Display Colors Infinite
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz (preferred resolution)
60 Hz (maximum resolution)
Synchronization (Horizontal) 30 to 54 KHz
Synchronization (Vertical) 50 to 120 Hz
