Weights &
Weights &Weights &
Weights &
Dimensions
DimensionsDimensions
Dimensions
(configured with 1 HDD &
1 ODD)
USDT
USDTUSDT
USDT
SFF
SFFSFF
SFF
CMT
CMTCMT
CMT
Chassis
(H x W x D)
2.6 x 9.9 x 10 in
66 x 252 x 254 mm
4.0 x 13.3 x 14.9 in
100 x 338 x 379 mm
17.6 x 7.00 x 18.0 in
448 x 178 x 445 mm
System Volume
257.5 cu in
4.2 L
782.77 cu in
12.8 L
2160 cu in
35.4 L
Tower Stand
(H x W x D)
1.1 x 4.9 x 6.7 in
27 x 125 x 170 mm
1.1 x 7.0 x 7.9 in
29 x 178 x 200 mm
N/A
Packaging
(H x W x D)
8.6 x 15.7 x 19.7 in
218 x 398 x 500 mm
9.0 x 19.7 x 23.4 in
229 x 500 x 594 mm
22.6 x 12.7 x 24.4 in
575 x 323 x 620 mm
System Weight
*
6.8 lb
3.1 kg
16.7 lb
7.6 kg
24.5 lb
11.2 kg
Shipping Weight
*
14.4 lb
6.5 kg
17.9 lb
8.1 kg
34.0 lb
15.4 kg
Max Supported Weight
(desktop orientation)
77.0 lb
35.0 kg
77.0 lb
35.0 kg
77.0 lb
35.0 kg
I/O Ports
I/O PortsI/O Ports
I/O Ports
USDT
USDTUSDT
USDT
SFF/CMT
SFF/CMTSFF/CMT
SFF/CMT
USB 2.0
Front – four (4) ports
Rear – six (6) ports
Serial
N/A
one RS-232 compatible port standard
second port available optionally
Parallel
N/A
one port available as an option
eSATA
N/A
one port available as an option
PS/2
color coded support for keyboard (purple) and mouse (green)
Video
VGA and DisplayPort v1.1a provide integrated dual independent monitor support
DVI output
available via optional DisplayPort to DVI Adapter
Audio
Front – microphone & headphone
Rear – line input (supports microphone or line input), line out
All ports are 3.5mm in diameter
NOTE:
NOTE:NOTE:
NOTE:
See Audio/Visual section for information on re-taskable audio ports.
NIC
Industry standard RJ-45 port accesses the integrated network interface controller
QuickSpecs
HP Compaq 8200 Elite Series
HP Compaq 8200 Elite SeriesHP Compaq 8200 Elite Series
HP Compaq 8200 Elite Series
Technical Specifications
DA - 13879 North America — Version 10 — June 13, 2011
Page 18
