* Only supported when using a dual link DVI or DisplayPort monitor connection
NOTE:
NOTE:NOTE:
NOTE: 60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital
connections.
AMD Radeon HD 6570 Graphics Card
AMD Radeon HD 6570 Graphics CardAMD Radeon HD 6570 Graphics Card
AMD Radeon HD 6570 Graphics Card
Form Factor
Form FactorForm Factor
Form Factor
PCI Express x16 (generation 2.0)
Low Profile, half length, 2.3" x 6.6"
Includes full height bracket when configured in CMT or MT chassis.
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller AMD HD 6570 GPU
Output Connector
Output ConnectorOutput Connector
Output Connector
Two (2) DisplayPort 1.1
One (1) Dual Link DVI-I
Includes a DVI-I to VGA adapter. Other optional adapter kits are available to support DVI-D, and
HDMI monitor inputs (see complete listing of available optional adapters elsewhere in this
QuickSpec).
Supports audio with video through the DisplayPort 1.1 connector. Audio is also supported with an
optional DisplayPort to HDMI Adapter.
DisplayPort 1.2 support will be provided in a future driver update.
Core Clock
Core ClockCore Clock
Core Clock 650MHz
Memory Clock
Memory ClockMemory Clock
Memory Clock 900MHz
Memory Frame Buffer
Memory Frame BufferMemory Frame Buffer
Memory Frame Buffer 1GB of DDR3,128-bit wide
Supported Graphics APIs
Supported Graphics APIsSupported Graphics APIs
Supported Graphics APIs
HDCP supported on DisplayPort and DVI output.
DirectX 11 support in hardware.
OpenGL 4.0 support in hardware
Display Resolutions and Refresh Rates
Display Resolutions and Refresh RatesDisplay Resolutions and Refresh Rates
Display Resolutions and Refresh Rates
NOTE:
NOTE:NOTE:
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution
ResolutionResolution
Resolution Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)
Analog
AnalogAnalog
Analog Digital
DigitalDigital
Digital
640 x 480 85 60
800 x 600 85 60
1024 x 768 85 60
1280 x 720 85 60
1280 x 1024 85 60
1440 x 900 75 60
1600 x 1200 85 60
1680 x 1050 75 60
1920 x 1080 85 60-R
1920 x 1200 85 60-R
1920 x 1440 85 60
2048 x 1536 75 60
2560 x 1600 N/A 60
NOTE:
NOTE:NOTE:
NOTE: 60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital
connections.
QuickSpecs
HP Compaq 8200 Elite Series
HP Compaq 8200 Elite SeriesHP Compaq 8200 Elite Series
HP Compaq 8200 Elite Series
Technical Specifications - Graphics
DA - 13879 North America — Version 10 — June 13, 2011 Page 33
