1920 x 1080 85 60-R
1920 x 1200 85 60-R
1920 x 1440 85 N/A
2048 x 1536 75 N/A
NOTE:
NOTE:NOTE:
NOTE: 60-R denotes reduced blanking timings are used on single link DVI connections and may be sued with other digital
connections.
AMD Radeon HD 6450 Graphics Card
AMD Radeon HD 6450 Graphics CardAMD Radeon HD 6450 Graphics Card
AMD Radeon HD 6450 Graphics Card
Form Factor
Form FactorForm Factor
Form Factor
PCI Express x16 (Generation 2.0)
Low Profile, half length, 2.3" x 6.6"
Full height bracket utilized when configured to CMT or MT
Graphics Controller
Graphics ControllerGraphics Controller
Graphics Controller AMD HD 6450 GPU
Output Connector
Output ConnectorOutput Connector
Output Connector
One (1) DisplayPort1.1
One (1) Dual Link DVI-I
Includes a DVI to VGA adapter. Other optional adapter kits are available to support DVI-D, and
HDMI monitor inputs (see a complete listing of available optional adapters elsewhere in this
QuickSpec).
Supports audio with video through the DisplayPort 1.1 connector.
DisplayPort v1.2 support will be provided in a future driver update.
Core Clock
Core ClockCore Clock
Core Clock 625MHz
Memory Clock
Memory ClockMemory Clock
Memory Clock 800MHz
Memory Frame Buffer
Memory Frame BufferMemory Frame Buffer
Memory Frame Buffer 512MB, DDR3, 64-bit wide
Display Maximum Resolution
Display Maximum ResolutionDisplay Maximum Resolution
Display Maximum Resolution
Digital: 2560 x 1600
Analog: 2048 x 1536
(see chart below for more resolutions)
Supported Graphics APIs
Supported Graphics APIsSupported Graphics APIs
Supported Graphics APIs
HDCP supported on DisplayPort 1.1 and DVI output.
DirectX 11 support in hardware.
Display Resolutions and Refresh Rates
Display Resolutions and Refresh RatesDisplay Resolutions and Refresh Rates
Display Resolutions and Refresh Rates
NOTE:
NOTE:NOTE:
NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP
Resolution
ResolutionResolution
Resolution Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)Maximum Refresh Rate (Hz)
Maximum Refresh Rate (Hz)
Analog
AnalogAnalog
Analog Digital
DigitalDigital
Digital
640 x 480 85 60
800 x 600 85 60
1024 x 768 85 60
1280 x 720 85 60
1280 x 1024 85 60
1440 x 900 75 60
1600 x 1200 85 60
1680 x 1050 75 60
1920 x 1080 85 60-R
1920 x 1200 85 60-R
1920 x 1440 85 60 *
2048 x 1536 75 60 *
2560 x 1600 N/A 60 *
QuickSpecs
HP Compaq 8200 Elite Series
HP Compaq 8200 Elite SeriesHP Compaq 8200 Elite Series
HP Compaq 8200 Elite Series
Technical Specifications - Graphics
DA - 13879 North America — Version 10 — June 13, 2011 Page 32
