Solid-state drive specifications
Performance
Transfer modes supported
UDMA 0-4, Multiword-DMA 0-2, PIO 0-4
Sustained read 39 MB/sec
Sustained write 17 MB/sec
Characteristics
Interface
Parallel ATA (PATA)
MLC NAND flash capacity 8 GB, 16 GB
Electrical specifications
DC supply voltage
3.3 V +/– 5%
Standby current 300 µA (typical)
Active current Read = 130 mA (typical)
Write = 120 mA (typical)
Environmental specifications
Operating temperature
0°C to +70°C (32°F to 158°F)
Storage temperature -25°C to +85°C (-13°F to 185°F)
Operating altitude up to 24,384 m (80,000 feet)
Humidity 5% to 90% non-condensing
Shock 1,000 g
Acoustic noise 0 dB
Vibration 15 g (peak to peak)
Physical specifications
Connector
40-pin ZIF connector
Weight (8-GB model) 5.5 g
Weight (16-GB model) 7.0 g
Dimensions (8-GB model) 54 × 32 × 2.6 mm
Dimensions (16-GB model) 54 × 32 × 3.75 mm
Regulations and compliance RoHS, China RoHS, SGS ROHS, FCC, CE
UL – PCB Only
Solid-state drive specifications 91
