Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket, connector cable, rubber
isolators, or screws. These components are included in the Hard Drive Hardware Kit, spare part
number 664913-001.
Description Spare part number
500-GB, 5400-rpm 634932-001
320-GB, 5400-rpm 645193-001
250-GB, 5400-rpm 645191-001
Before removing the hard drive, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 50).
5. Remove the service cover (see
WLAN module on page 52).
Remove the hard drive:
1. Disconnect the hard drive connector cable (1) from the system board.
2. Remove the Phillips PM 2.0×5.0 screw (2) that secures the hard drive to the computer.
3. Use the pull tab (3) to lift the left side of the hard drive until it rests at an angle.
Component replacement procedures
59
