Product Description
Maintenance and Service Guide 1–21
Table 1-8
Bottom Components
Item Component Function
1 Base enclosure cover Covers the display cable connector.
2 Docking connector Connects the tablet PC to an optional
docking device.
3 Accessory battery
connector
Connects an optional HP Ultra-Capacity
Battery or HP Extended Life Battery.
4 Vents (3) Provides airflow to cool internal
components.
Ä
To prevent overheating, do not
obstruct vents. Use the computer
only a hard, flat surface. Do not
allow a hard surface, such as an
adjoining printer, or a soft
surface, such as pillows or thick
rugs or clothing, to block airflow.
5 Battery bay Holds the battery pack.
6 Battery release latch Releases the battery pack from the
battery bay.
7 Hard drive cover Holds the primary hard drive.
8 Expansion memory
module compartment
Contains one expansion memory
module slot.
