Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing tablet PC components.
Disassembly Sequence Chart
Section Description
# of Screws Removed
5.3 Preparing the Tablet PC for
Disassembly
Battery pack
0
5.4 Hard Drive 2 loosened to remove the
hard drive cover
1 loosened to remove the hard
drive
4 removed to disassemble the
hard drive
5.5 Tabl et P C Fe e t 0
5.6 Bluetooth Module 2 loosened to remove the
Bluetooth module cover
5.7 External Memory Module 2 loosened to remove the
memory module compartment
cover
5.8 Keyboard Cover 4
5.9 Keyboard 4
5.10 Fan 3
5.11 Heat Sink 4
5.12 Processor 1 loosened
5.13 Internal Memory Module 0
