HP D5259A - Pavilion M70 - 17" CRT Display User Manual

Pin Assignments and Signal Levels
Pin Assignments and Signal LevelsPin Assignments and Signal Levels
Pin Assignments and Signal Levels
15-Pin D-SUB male video connector
15-Pin D-SUB male video connector15-Pin D-SUB male video connector
15-Pin D-SUB male video connector
PIN NO.
PIN NO.PIN NO.
PIN NO. SIGNAL
SIGNALSIGNAL
SIGNAL PIN NO.
PIN NO.PIN NO.
PIN NO. SIGNAL
SIGNALSIGNAL
SIGNAL
1RED 9NC
2GREEN 10DIGITAL GROUND
3 BLUE 11 MONITOR SENSEI
4 DIGITAL GROUND 12 SDA (DDC1/2B)
5 RETURN (DDC2B) 13 H. SYNC.
6GROUND 14V. SYNC.
7 GROUND 15 SCL (DDC2B)
8GROUND
SIGNAL LEVEL
SIGNAL LEVELSIGNAL LEVEL
SIGNAL LEVEL
Note:
Note:Note:
Note:
The signal level at pin 1,2,3 is 0.7 Vp-p.
The signal level at pin 13,14 is 5 Vp-p.
1
6
11
17
1717
17
Pin Assignments and Signal Levels
Pin Assignments and Signal LevelsPin Assignments and Signal Levels
Pin Assignments and Signal Levels
