Hardware Reference Guide www.hp.com 2–3
Hardware Upgrades
3. Loosen the captive thumbscrew 1 that secures the access panel to
the computer chassis.
4. Slide the access panel 2 back about 1 inch (2.5 cm), then lift it
off the unit.
✎
You may want to lay the computer on its side to install internal parts.
Be sure the side with the access panel and pull grip is facing up.
Removing the Computer Access Panel
