Product Features
Rear Panel Components
Rear Panel Components
1 Power Cord Connector 7
n
RJ-45 Network Connector
2 Voltage Select Switch 8
l
Parallel Connector
3
b
PS/2 Mouse Connector 9
c
Monitor Connector
4
a
PS/2 Keyboard Connector -
h
Headphone/Line-Out Connector
5
o
Universal Serial Bus (USB) q
j
Line-In Audio Connector
6
m
Serial Connector w
g
Microphone Connector
✎
Arrangement and number of connectors may vary by model.
When a PCI graphics card is installed, the connectors on the card and the system board may be
used at the same time. Some settings may need to be changed in F10 setup to use both connectors.
In F10 setup, go to Advanced > PCI VGA Configuration to change the settings. For more
information about F10 setup, refer to the Computer Setup (F10) Utility Guide on the Documentation
CD.
