HP dx2310 - Microtower PC User Manual

6–2 490778-001 Service Reference Guide
Removal and Replacement Procedures— Microtower (MT) Chassis
6.2 Remove the computer access panel and front bezel
(
MT chassis)
6.2.1 Access Panel (MT Chassis)
1. Prepare the computer for disassembly (Section 6.1, “Preparation for Disassembly”).
Ä
CAUTION: Before removing the computer access panel, ensure that the computer is turned off and that
the power cord is disconnected from the electrical outlet.
2. Disconnect the power cord from the computer and from the power source.
3. Remove the screw that secures the access panel to the computer chassis 1.
4. Slide the access panel back about 10 mm (3/8 inch), then lift it away from and off the unit 2.
To replace the access panel, reverse the removal steps.

HP dx2310 - Microtower PC Specifications

General

Brand	HP
Model	dx2310 - Microtower PC
Category	Desktop
Language	English
