NOTE: The host computer must be able to support DisplayPort Alt Mode (video, charging, and USB 3.1) over
the USB Type-C connector and must also be compatible with USB Type-C, Thunderbolt-enabled ports.
Connecting two host computers to the docking monitor might result in system shutdown, loss of power, and
the need to turn o and restart the monitor.
To dock a computer, connect one end of a USB Type-C cable to the USB Type-C port on the rear of the monitor
and the other end to the USB Type-C port on the computer. This USB Type-C cable provides single-cable
connectivity for high-speed data, audio and video, and power delivery.
NOTE: The monitor delivers up to 65 W of power over a USB Type-C connection. When connecting the host
computer via USB Type-C, DC power out does not need to be connected. Do not connect two power sources
(DC power in and USB Type-C) to the host computer.
Docking an HP notebook or desktop computer 17

Table of Contents

Other manuals for HP E14 G4

Preview: Quick Setup
Quick Setup2 pages
Preview: Maintenance And Service Guide
Maintenance And Service Guide20 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP E14 G4 and is the answer not in the manual?

HP E14 G4 Specifications

General IconGeneral
Color gamut72 %
Pixel pitch0.161 x 0.161 mm
Screen shapeFlat
Pixel density157 ppi
Display diagonal14 \
Display technologyLED
Native aspect ratio16:9
Vertical scan range59 - 60 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 80 kHz
Contrast ratio (typical)800:1
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Built-in USB hubYes
DisplayPorts quantity0
USB upstream port typeUSB Type-C
Power consumption (standby)0.3 W
Power consumption (typical)6 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Package depth61 mm
Package width405 mm
Package height284 mm
Package weight1540 g
Tilt angle range0 - 78 °
CertificationBIS; BSMI; CB; CCC; CE; cTUVus; EAC; ENERGY STAR®; FCC; ICES; ISE for Cambodia; ISO 9241-307; KC/KCC; NOM; SEPA; Taiwan Green Mark; TUV/GS; VCCI; Vietnam MEPS; WEEE; ISC; WW application; UAE
Product colorWhite
Market positioningBusiness
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)15.2 mm
Width (with stand)321.4 mm
Height (with stand)210 mm
Weight (with stand)640 g
