HP E22 G5 User Manual

2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Depending on the model, your monitor might include the following features:
● 54.60 cm (21.5 in), plus full-screen support for lower resolutions; includes custom
scaling for maximum image size while preserving original aspect ratio
● sRGB 99%
● Anti-glare panel with an LED backlight
● Ergonomic monitor setup guide (via the HP Display Center software) during first time
use
● Tilt, swivel, height-adjustable, and pivot capabilities
● On-screen display (OSD) adjustments in several languages for easy setup and screen
optimization
● Joypad OSD navigation
● Energy saver feature to meet requirements for reduced power consumption
● HP Eye Ease (TUV Low Blue Light Hardware Solution certified and 75 Hz Max Refresh rate)
● Compatible with displays software including:
● HP Display Center
● HP Display Manager
● Secure firmware updates with HP Display Center
● Security cable slot on the rear of the monitor for an optional security cable
● Cable management feature for placement of cables and cords
● High-Definition Multimedia Interface® (HDMI®) video input
● USB Type-B port
● USB Type-A port
● Plug and Play capability, if supported by your operating system
● Removable stand for flexible monitor head mounting solutions
● VESA® mounting capability (100 × 100 mm) for attaching the monitor to a swing arm
mount
NOTE: For safety and regulatory information, refer to the Product Notices provided in your
documentation kit. To access the latest user guides or manuals for your product, go to
http://www.hp.com/support and follow the instructions to find your product. Then select
Manuals.

HP E22 G5 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.25 x 0.25 mm
Screen shape	Flat
Pixel density	102 ppi
Backlight type	Edge LED
Display diagonal	21.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	54.62 cm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	140 mm
Package width	571 mm
Package height	363 mm
Package weight	6800 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Height adjustment	150 mm
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	ENG, ESP, FRE, ITA, JPN, POR, RUS
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	211 mm
Width (with stand)	488.7 mm
Height (with stand)	492.95 mm
Weight (with stand)	4900 g
Depth (without stand)	46 mm
Height (without stand)	293.9 mm
Weight (without stand)	2900 g
