HP E24 G5 User Manual

3
2 Monitor features
This chapter provides an overview of the monitor’s features.
Features
Display features
● 54.60 cm (21.5 in), 60.50 cm (23.8 in), plus full-screen support for lower resolutions; includes
custom scaling for maximum image size while preserving original aspect ratio
● True 8 bit (QHD only)
● sRGB 99%
● Anti-glare panel with an LED backligh
● Touch screen capability (select product only)
● Ergonomic monitor setup guide (via the HP Display Center software) during first time use
● Tilt, swivel, height-adjustable, and pivot capabilities
● On-screen display (OSD) adjustments in several languages for easy setup and screen optimization
● Joypad OSD navigation
● Energy saver feature to meet requirements for reduced power consumption
● HP Eye Ease (TUV Low Blue Light Hardware Solution certified and 75 Hz Max Refresh rate)
● Compatible with displays software including:
- HP Display Center
- HP Display Manager
● Secure firmware updates with HP Display Center
● Security cable slot on the rear of the monitor for an optional security cable
● Cable management feature for placement of cables and cords
Connectors
● DisplayPort™ video input
● High-Definition Multimedia Interface® (HDMI®) video input
● USB Type-B port
● USB Type-A port
● Plug and Play capability, if supported by your operating system
Monitor stand
● Removable stand for flexible monitor head mounting solutions
● VESA® mounting capability (100 × 100 mm) for attaching the monitor to a swing arm mount
NOTE: For safety and regulatory information, see Legislation and regulations on page 39. To access the
latest user guide, go to http://www.hp.com/support, and follow the instructions to find your product. Then
select Manuals..

HP E24 G5 Specifications

General

Color depth	8 bit
Pixel pitch	0.27 x 0.27 mm
Screen shape	Flat
Pixel density	93 ppi
Backlight type	Edge LED
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 86 kHz
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	60.5 cm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Pivot angle	-90 - 90 °
Cable lock slot	-
Panel mounting interface	100 x 100 mm
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	140 mm
Package width	621 mm
Package height	400 mm
Package weight	7600 g
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	53 W
Power consumption (standby)	0.5 W
Power consumption (typical)	22 W
Cables included	DisplayPort, HDMI, USB Type-A to USB Type-B

Weight and Dimensions

Depth (with stand)	211 mm
Width (with stand)	539.4 mm
Height (with stand)	507 mm
Weight (with stand)	5400 g
Depth (without stand)	47 mm
Height (without stand)	322.6 mm
