This procedure includes USB3.0 connectors
The connectors is on USB board (board part number USBPQAE).
The connector identifiers are as follows:
Connector
Location
USB 3.0
CN1032
USB 3.0
CN1033
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 14
.
IMPORTANT:
• Repair Condition: Connector repair is only for out of warranty.
• Repairing must operate by professional repairers (Note) in repair center, not applicable for end
user.
• Electrostatic protection is required when component replacement is required.
• The monitor meets ROHS, please use Lead-free solder wire for soldering.
• If Connector need to replace, must check specification and part number whether match the BOM
and location.
CN610
CN1033
CN1032
AUDIO BOARD
USB BOARD

HP E27m G4 Specifications

General

Color gamut	99 %
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Backlight type	Edge LED
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	50 - 75 Hz
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440
Product color	Black, Silver
Market positioning	Business
Megapixel	5 MP
RMS rated power	10 W
Number of speakers	2
Pivot angle	-90 - 90 °
Cable lock slot	-
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	160 W
Power consumption (standby)	0.5 W
Power consumption (typical)	51 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
HDMI version	1.4
DisplayPort version	1.2
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
Cables included	AC, USB Type-C to USB Type-C
Package depth	190 mm
Package width	695 mm
Package height	483 mm
Package weight	11970 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	216 mm
Height (with stand)	551 mm
Weight (with stand)	8520 g
Depth (without stand)	47 mm
Width (without stand)	612.8 mm
Height (without stand)	396.6 mm
