HP EliteBook 850 G1 User Manual

5 Removal and replacement
procedures for Customer Self-
Repair parts
CAUTION: The Customer Self-Repair program is not available in all locations. Installing a part not
supported by the Customer Self-Repair program may void your warranty. Check your warranty to
determine if Customer Self-Repair is supported in your location.
Component replacement procedures
This chapter provides removal and replacement procedures.
There are as many as 15 screws that must be removed, replaced, and/or loosened when servicing
the Customer Self-Repair parts. Make special note of each screw size and location during removal and
replacement.
Service cover
Description Spare part number
Service cover for use only on HP EliteBook 840 models 730960-001
Service cover for use only on HP EliteBook 840 models; no CCC mark 745313-001
Service cover for use only on HP EliteBook 840/HP ZBook 14 models; RCTO 745311-001
Service cover for use only on HP ZBook 14 models 730961-001
Service cover for use only on HP ZBook 14 models; no CCC mark 745314-001
Service cover for use only on HP EliteBook 850 models 730812-001
Service cover for use only on HP EliteBook 850 models; without CCC mark 745309-001
Service cover for use only on HP EliteBook 850 models; for RCTO 745310-001
48 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts

HP EliteBook 850 G1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Intel® vPro™ Platform Eligibility	No
Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x4
Thermal Design Power (TDP)	15 W
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	256 GB
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0xA16
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1000 MHz
Intel segment tagging	Enterprise
Audio system	DTS Studio Sound
4G standard	LTE
3G standards	HSPA
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	4G
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Pointing device	Touchpad + Pointing Stick
Bundled software	HP 3D DriveGuard\\r HP Connection Manager (Windows 7)\\r HP Wireless HotSpot\\r HP Mobile Connect (EMEA)\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r HP 3D DriveGuard
Operating system installed	Windows 7 Professional
Optional operating system supplied	Windows 8.1 Pro
Processor code	SR170
Processor ARK ID	75459
Intel TSX-NI version	0.00
Processor package size	40 x 24 x 1.5 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0
Intel Smart Connect Technology version	1.00
Battery capacity	50 Wh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W

Weight and Dimensions

Depth	253.6 mm
Width	375.5 mm
Weight	1880 g
Height (front)	21.4 mm
