6 Removal and replacement
procedures for Authorized Service
Provider parts
CAUTION: Components described in this chapter should only be accessed by an authorized service
provider. Accessing these parts can damage the computer or void the warranty.
Component replacement procedures
NOTE: Details about your computer, including model, serial number, product key, and length of
warranty, are on the service tag at the bottom of your computer. See Service tag and PCID label on
page 21 for details.
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 61 screws that must be removed, replaced, and/or loosened when servicing
the Authorized Service Provider parts. Make special note of each screw size and location during
removal and replacement.
Display panel (non-touch)
NOTE: HP EliteBook 840 models offer both touch and non-touch displays. Non-touch displays are
spared at the subcomponent level only. Touch displays are only spared as a whole (touch display
components are not spared).
In non-touch models, you can remove the raw display panel with the display assembly still connected to
the computer. The following section shows how to remove the raw display panel without removing the
display assembly from the computer.
See
Display assembly on page 97 later in this chapter to remove internal components that require
that you remove the display assembly.
Description Spare part number
Display bezel
Display bezel for use in HP EliteBook 840 models 730952-001
Display bezel for use in HP ZBook 14 models 730953-001
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
