HP EliteBook 850 G3 User Manual

System board
NOTE: All system board spare part kits include replacement thermal material.
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Description Spare part number
Intel i7-6600U for HP 840; UMA graphics memory 826808-xxx
Intel i7-6500U for HP 840; UMA graphics memory 826807-xxx
Intel i5-6300U for HP 840; UMA graphics memory 826806-xxx
Intel i5-6200U for HP 840; UMA graphics memory 826805-xxx
Intel i3-6100U for HP 840; UMA graphics memory 826804-xxx
Intel i7-6600U for HP 850; UMA graphics memory 832424-xxx
Intel i7-6500U for HP 850; UMA graphics memory 832423-xxx
Intel i5-6300U for HP 850; UMA graphics memory 832422-xxx
Intel i5-6200U for HP 850; UMA graphics memory 832421-xxx
Intel i3-6100U for HP 850; UMA graphics memory 832420-xxx
Intel i7-6600U for HP 850; discrete graphics memory 832429-xxx
Intel i7-6500U for HP 850; discrete graphics memory 832428-xxx
Intel i5-6300U for HP 850; discrete graphics memory 832427-xxx
Intel i5-6200U for HP 850; discrete graphics memory 832426-xxx
Intel i3-6100U for HP 850; discrete graphics memory 832425-xxx
Intel i7-6600U for HP ZBook 15u; discrete graphics memory 839236-xxx
Intel i7-6500U for HP ZBook 15u; discrete graphics memory 839235-xxx
Intel i5-6300U for HP ZBook 15u; discrete graphics memory 839234-xxx
Intel i5-6200U for HP ZBook 15u; discrete graphics memory 839233-xxx
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 35).
5. Remove the battery (see Battery on page 40).
6. Remove the following components:
72 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP EliteBook 850 G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Silver
Country of origin	China
Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-6500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6500 Mobile series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Numeric keypad	Yes
Pointing device	Touchpad
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	46 Wh
Number of battery cells	3
AC adapter power	65 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Processor code	SR2EZ
Processor ARK ID	88194
Processor package size	42 X 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise
HP segment	Business
HP Software provided	HP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software, HP Clear Sound Amp

Weight and Dimensions

Depth	257.7 mm
Width	383.3 mm
Height	19.4 mm
Weight	1880 g
