Heat sink assembly
NOTE: The heat sink assembly spare part kit includes replacement thermal material.
Table 6-2 Heat sink descriptions and part numbers
Description Spare part number
Heat sink for use in models with discrete graphics memory L65693-001
Heat sink for use in models with UMA graphics memory L65692-001
Before removing the heat sink assembly, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Disconnect the battery cable from the system board (see Battery on page 44).
Remove the heat sink assembly:
1. Discrete graphics models: Loosen the six captive screws on the heat sink following the sequence
stamped on the heat sink (1), and then remove the heat sink from the system board (2).
IMPORTANT: Take extreme care when removing the heat sink. The heatpipe is very fragile and can be
easily damaged and bent during removal.
46 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP EliteBook 850 G6 Specifications

General

Storage	Up to 2 TB PCIe NVMe SSD
Operating System	Windows 10 Pro
Processor	8th Generation Intel Core i5 or i7 processors
Display	15.6-inch diagonal FHD (1920 x 1080) or UHD (3840 x 2160)
Memory	Up to 32 GB DDR4-2400 SDRAM
Graphics	Intel UHD Graphics or AMD Radeon
Battery	3-cell, 56 Wh Li-ion
Ports	1 HDMI 1.4b, 1 headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth Combo
Audio	Bang & Olufsen, dual stereo speakers
Weight	Starting at 1.78 kg
