HP EliteBook 850 G6 User Manual

USB board
Table 6-4 USB board description and part number
Description Spare part number
USB board L65689-001
Before removing the USB board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Remove the bottom cover (see Bottom cover on page 32).
3. Disconnect the battery cable from the system board (see Battery on page 44).
Remove the USB board:
1. Disconnect the cable from the ZIF connector on the USB board (1).
2. Remove the Phillips M2.0 × 3.0 screw (2) that secures the board to the computer.
3. Remove the board from the computer (3).
Reverse this procedure to install the USB board.
50 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP EliteBook 850 G6 Specifications

General

Storage	Up to 2 TB PCIe NVMe SSD
Operating System	Windows 10 Pro
Processor	8th Generation Intel Core i5 or i7 processors
Display	15.6-inch diagonal FHD (1920 x 1080) or UHD (3840 x 2160)
Memory	Up to 32 GB DDR4-2400 SDRAM
Graphics	Intel UHD Graphics or AMD Radeon
Battery	3-cell, 56 Wh Li-ion
Ports	1 HDMI 1.4b, 1 headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth Combo
Audio	Bang & Olufsen, dual stereo speakers
Weight	Starting at 1.78 kg
