HP Envy 15 User Manual

Item Component Spare part number
(1) Display assembly (includes webcamera/microphone module and wireless antenna cables):
15.6 inch (39.80 cm), BrightView, FHD, LED, TouchSmart touchscreen display
assembly
720550-001
15.6 inch (39.80 cm), BrightView, HD, LED, TouchSmart touchscreen display
assembly
720549-001
15.6 inch (39.80 cm), BrightView, FHD, LED, non-touchscreen display assembly 720552-001
15.6 inch (39.80 cm), BrightView, HD, LED, non-touchscreen display assembly 720551-001
The subcomponents for the non-touchscreen display assembly are also available as spare part kits. For more
display assembly spare part information, see
Display assembly subcomponents on page 25.
(2) Top cover 720570-001
(3) Power button board (includes cable) 720553-001
(4) Keyboard (includes keyboard cable):
Keyboard with backlight (includes backlight cable):
For use on computer models equipped with an Intel processor in Belgium 720244-A41
For use in Canada 720244-DB1
For use on computer models equipped with an Intel processor in the Czech Republic
and Slovakia
720244-FL1
For use on computer models equipped with an Intel processor in Denmark, Finland,
and Norway
720244-DH1
For use on computer models equipped with an Intel processor in France 720244-051
For use on computer models equipped with an Intel processor in Germany 720244-041
For use on computer models equipped with an Intel processor in Greece 720244-151
For use on computer models equipped with an Intel processor for use internationally 720244-B31
For use on computer models equipped with an Intel processor in Italy 720244-061
For use on computer models equipped with an Intel processor in Japan 720244-291
For use in Latin America 720244-161
For use on computer models equipped with an Intel processor in Portugal 720244-131
For use on computer models equipped with an Intel processor in Russia 720244-251
For use on computer models equipped with an Intel processor in Saudi Arabia 720244-171
For use on computer models in South Korea 720244-AD1
For use on computer models equipped with an Intel processor in Spain 720244-071
For use on computer models equipped with an Intel processor in Switzerland 720244-BG1
For use on computer models equipped with an Intel processor in Taiwan 720244-AB1
For use on computer models equipped with an Intel processor in Thailand 720244-281
For use on computer models equipped with an Intel processor in Turkey 720244-141
For use on computer models equipped with an Intel processor in the United Kingdom 720244-031
20 Chapter 3 Illustrated parts catalog

HP Envy 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Accelerometer	Yes
Motherboard chipset	Intel SoC
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	2 x 4 GB
3D	No
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Pointing device	Touchpad
Operating system architecture	64-bit
Battery capacity	52 Wh
Battery life (max)	9 h
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Cable lock slot type	Kensington
Package depth	305 mm
Package width	520 mm
Package height	69 mm
Package weight	3510 g
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Sustainability certificates	EPEAT Silver, ENERGY STAR
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Processor code	SR2ZU
Processor ARK ID	95443
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	255 mm
Width	380 mm
Height	17.9 mm
Weight	1930 g
