Page #41 background imageLoading...
Page #41 background image
Using operating system controls
The Network and Sharing Center allows you to set up a connection or network, connect to a network,
manage wireless networks, and diagnose and repair network problems.
To use operating system controls:
Mode Steps
1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap
Search, and then tap the search box.
2. Type network and sharing in the search box, and then select Network and Sharing
Center.
1. From the Start screen, type n, and then select Settings.
2. Type network and sharing in the search box, and then select Network and Sharing
Center.
For more information, access HP Support Assistant. To access HP Support Assistant, on the Start
screen, select the HP Support Assistant app
Using a WLAN
With a WLAN device, you can access a wireless local area network (WLAN), which is composed of
other devices and accessories that are linked by a wireless router or a wireless access point.
NOTE: The terms wireless router and wireless access point are often used interchangeably.
A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points
that can accommodate a large number of devices and accessories and can separate critical
network functions.
A home or small office WLAN typically uses a wireless router, which allows several wireless and
wired devices to share an Internet connection, a printer, and files without requiring additional
pieces of hardware or software.
To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided
through a service provider or a public or corporate network).
Using an Internet service provider
When you are setting up Internet access in your home, you must establish an account with an
Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The
ISP will help set up the modem, install a network cable to connect your wireless router to the modem,
and test the Internet service.
NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this
information and store it in a safe place.
Connecting to a wireless network 31

Table of Contents

Other manuals for HP ENVY x2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ENVY x2 and is the answer not in the manual?

HP ENVY x2 Specifications

General IconGeneral
SteppingC0
Processor cache1 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel Atom®
Processor seriesIntel Atom Z2700 Series
Processor socketFC-MB4760
Processor threads4
Processor codenameCloverview
Processor frequency1.8 GHz
Processor cache typeL2
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
Processor operating modes32-bit
ECC supported by processorNo
Thermal Design Power (TDP)- W
Motherboard chipset-
Internal memory2 GB
Memory clock speed533 MHz
Memory form factorOn-board
Internal memory typeDDR2-SDRAM
Memory layout (slots x size)1 x 2 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Storage mediaSSD
Card reader integratedYes
Total storage capacity64 GB
Compatible memory cardsSD
Number of SSDs installed1
Display surfaceMatt
Display diagonal11.6 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Discrete graphics card modelNot available
Audio systemBeats Audio
Front camera resolution (numeric)8 MP
Data networkNot supported
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Charging port typeDC-in jack
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Operating system installedWindows 8
Form factorConvertible (Detachable)
Product typeHybrid (2-in-1)
Product colorSilver
Housing materialMetal
Country of originChina
Processor codeSR0Z4
Processor ARK ID70105
Processor package size14 x 14 mm
Battery life (max)7 h
Number of battery cells2+2
AC adapter power20 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Sustainability certificatesRoHS, EPEAT Silver, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth206 mm
Width303 mm
Height19 mm
Weight1390 g
