Figure 29 SAS cabling showing five storage enclosures below the head server
1
2
3
4 1
5
6
4
4
1
iLO
PS2
6
7
8
1
2
3
4
5
JBOD22JBOD11
JBOD44JBOD33
SAS connector on RAID controller on head
unit
6JBOD55
P2 connector on I/O module (SAS OUT to next
expansion shelf)
8P1 connector on I/O module (SAS IN from
head unit or previous expansion shelf)
7
12. When the enclosure has completed its power on sequence, check all enclosure status LEDs
to ensure the enclosure is operating properly.
13. Power on the HPE StoreOnce 5100 System.
Removing and replacing an enclosure 67
