HP J9145A User Manual

1-15
Introducing the Switch
Features
Introducing the Switch
Features
Figure 2. Front of the al 10-GbE CX4 Module
The al Modules have the following features:
■ Connectivity ports.
■ LEDs that provide information for each port on the link and mode status.
■ LED that provides information on module status.
■ “hot swap transceiver” support—you can add, replace, or change the type
of any of the transceivers that you use in the SFP+ module ports, without
having to first remove the module, and without having to shut down the
switch.
Standards adherence:
■ IEEE 802.3ak CX4
■ IEEE 802.3ae XAUI
HP ProCurve 10-GbE CX4 al Module
Module Status
LEDs
Retaining screw
Copper CX4 port connections
Link and Mode LEDs
(one pair per port)

HP J9145A Specifications

General

Brand	HP
Model	J9145A
Category	Switch
Language	English
