2-27
Installing the Switch
Sample Network Topologies
Installing the Switch
Sample Network Topologies
This section shows a few sample network topologies in which the switch is
implemented. For more topology information, see the ProCurve network
products Website, www.procurve.com.
Figure 2-19. Example, gigabit edge deployment
The Switch 2910al can be used at the edge of the network to which end nodes,
printers and other peripherals, are directly connected, as shown in the above
illustration. Notice that the end node devices are connected to the switch by
gigabit copper cable, straight-through or crossover twisted-pair cables.
Servers
PCs and peripherals
ProCurve Switch 5406zl
Gigabit fiber cable
Gigabit copper cable
ProCurve Switch 2910al
