2-17
Installing the Switch
Installation Procedures
6. Installing or Removing SFPs
You can install or remove an SFP from an SFP slot without having to power
off the switch. Use only HP SFPs (see Table 1-1 on page 1-4).
Caution Hot swapping transceivers is supported. You can install or remove a
transceiver with the switch powered on, a reset will not occur. However, rapid
hotswaps are not recommended. Wait a few seconds for the Mode LED to turn
on (during initialization), and then turn off.
Notes Ensure the network cable is NOT connected when you install or remove an
SFP.
Caution Use only supported genuine HP SFPs with your switch. Non-HP SFPs are not
supported, and their use may result in product malfunction. Should you
require additional HP SFPs, contact your HP Networking Sales and Service
Office or authorized dealer.
Installing the SFPs:
Remove the protective plastic cover and retain it for later use. Hold the SFP
by its sides and gently insert it into any of the slots on the switch until the SFP
clicks into place.
WARNING The fiber-optic HP SFPs are Class 1 laser devices. Avoid direct eye
exposure to the beam coming from the transmit port.
Figure 2-10. Installing an SFP
