Specifications
User’s Guide www.hp.com B–3
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used
modes and are set as factory defaults. This monitor automatically
recognizes these preset modes and they will appear properly sized
and centered on the screen.
Factory Preset Display Modes
Preset Pixel Format
Horz Freq
(kHz) Vert Freq (Hz)
1 640 x 480 31.5 60.0
2640 x 480 37.5 75.0
3640 x 480 43.3 85.0
4 720 x 400 31.5 70.1
5 800 x 600 37.9 60.3
6 800 x 600 53.7 85.1
7832 x 624 49.7 75.0
8 1024 x 768 48.4 60.0
9 1024 x 768 60.0 75.0
10 1024 x 768 68.7 85.0
11 1152 x 870 69.0 75.1
12 1152 x 900 61.8 66.0
(Sun Mode II)
13 1280 x 960 60.0 60.0
14 1280 x 1024 64.0 60.0
15 1280 x 1024 80.0 75.0
16 1280 x 1024 91.2 85.0
17 1600 x 1200 75.0 60.0
18 1600 x 1200 93.8 75.0
