21
Preset Display Modes
Preset
Pixel
Format
Horz Freq
(kHz)
Horz
Polarity
Vert Freq
(Hz)
Vert
Polarity
Pixel Clk
(MHz)
Source
1 640 x 480 31.469 - 59.940 - 25.175 VGA
2 720 x 400 31.469 - 70.087 + 28.322 VGA
3 800 x 600 37.87 + 60.317 + 40.000 VESA
4 1024x768 48.36 - 60.000 - 65.000 VESA
5 1280x960 60.00 ± 60.000 ± 108.000 VESA
6 1280x1024 63.98 + 60.020 + 108.000 VESA
7 1440x900 55.94 - 59.890 + 106.500
CVT
1.30MA
8 1600x1200 75.00 + 60.000 + 106.500 VESA
9 1680x1050 65.29 - 60.000 + 146.250
CVT
1.76MA
10 1920x1080 67.50 + 60.000 + 148.500 CEA-861
