HP LP1965 User Manual

ENWW
Maintenance Guidelines
To enhance the performance and extend the life of the monitor:
●
Do not open the monitor cabinet or attempt to service this product yourself. Adjust only those
controls that are covered in the operating instructions. If the monitor is not operating properly or
has been dropped or damaged, contact an authorized HP dealer, reseller, or service provider.
●
Use only a power source and connection appropriate for this monitor, as indicated on the label/
back plate of the monitor.
●
Be sure the total ampere rating of the products connected to the outlet does not exceed the
current rating of the electrical outlet, and the total ampere rating of the products connected to
the cord does not exceed the rating of the cord. Look on the power label to determine the
ampere rating (AMPS or A) for each device.
●
Install the monitor near an outlet that you can easily reach. Disconnect the monitor by grasping
the plug firmly and pulling it from the outlet. Never disconnect the monitor by pulling the cord.
●
Turn the monitor off when not in use. You can substantially increase the life expectancy of the
monitor by using a screen saver program and turning off the monitor when not in use.
●
Slots and openings in the cabinet are provided for ventilation. These openings must not be
blocked or covered. Never push objects of any kind into cabinet slots or other openings.
●
Do not drop the monitor or place it on an unstable surface.
●
Do not allow anything to rest on the power cord. Do not walk on the cord.
●
Keep the monitor in a well-ventilated area, away from excessive light, heat or moisture.
●
When removing the monitor base, you must lay the monitor face down on a soft area to prevent
it from getting scratched, defaced, or broken.
Cleaning the Monitor
1. Turn off the monitor and the computer.
2. Unplug the monitor from the wall outlet.
3. Clean the monitor plastics with a clean cloth dampened with water.
4. Clean the monitor screen with an antistatic screen cleaner.
CAUTION Do not use benzene, thinner, ammonia, or any other volatile substances to clean
the monitor or the screen. These chemicals may damage the cabinet finish as well as the
screen.
Shipping the Monitor
Keep the original packing box in a storage area. You may need it later if you move or ship the monitor.
Chapter 2 Safety and Maintenance Guidelines 4

HP LP1965 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-4 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	4:3
Response time	6 ms
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	48 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
Audio included	No audio included No audio included at platform level
Rear ports note	4 USB 2.0
Native resolution	SXGA (1280x1024) pixels
Security features	Kensington Lock-ready
Weight (imperial)	15.6 lb lbs
Power requirements	Auto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequency	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)	15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)	15.9 x 2.4 x 12.96 \
Product color	Black, Silver
Country of origin	China
AC input voltage	90 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	55 W
Power consumption (standby)	2 W
Power consumption (typical)	35 W
I/O ports	One upstream, four downstream ports (cable included)
USB hub version	2.0
DVI-D ports quantity	0
DVI-I ports quantity	2
USB Type-A downstream ports quantity	3
Cables included	AC, DVI
Interface adapters included	DVI-I female - VGA male

Weight and Dimensions

Depth (with stand)	222.9 mm
Width (with stand)	403.9 mm
Height (with stand)	377.2 mm
Weight (with stand)	7060 g
Depth (without stand)	61 mm
Height (without stand)	329.1 mm
Weight (without stand)	4190 g
