HP LP1965 User Manual

ENWW
A Troubleshooting
Solving Common Problems
The following table lists possible problems, the possible cause of each problem, and the
recommended solutions.
Problem Possible Cause Solution
Screen is blank. Power cord is disconnected. Connect the power cord.
Power switch on front panel of the
monitor is turned off.
Press the front panel power button.
Master power switch on rear panel
of the monitor is turned Off.
Turn the master power switch to On.
Video cable is improperly
connected.
Connect the video cable properly. Refer to Chapter 3,
Setting Up the Monitor for more information.
Screen blanking is active. Press any key on the keyboard or move the mouse to
inactivate the screen blanking utility.
Image appears blurred,
indistinct, or too dark.
Brightness and contrast are too
low.
Press the —/Auto button on the front panel. If this does
not correct the image, press the Menu button to open the
Basic OSD Menu, and adjust the brightness and contrast
scales as needed.
Image is not centered Position may need adjustment. Press the Menu button to access the OSD menu. Select
Image Control/Horizontal Position or Vertical Position to
adjust the horizontal or vertical position of the image.
Check Video Cable is
displayed on screen.
Monitor video cable is
disconnected.
Connect the DVI-D signal cable to the DVI-I connector
on the computer, or the VGA to DVI-I cable to the DVI-I
connector on the computer. Be sure that the computer
power is off while connecting the video cable.
Out of Range. Set
Monitor to 1280 × 1024
@ 60Hz is displayed on
screen. (LP1965 19" model)
Video resolution and/or refresh
rate are set higher than what the
monitor supports.
Restart the computer and enter Safe Mode. Change the
settings to a supported setting (see Table B-4 LP1965
Model Factory Preset Modes). Restart the computer so
that the new settings take effect.
Out of Range. Set
Monitor to 1600 × 1200
@ 60Hz is displayed on
screen. (LP2065 20" model)
Video resolution and/or refresh
rate are set higher than what the
monitor supports.
Restart the computer and enter Safe Mode. Change the
settings to a supported setting (see Table B-5 LP2065
Model Factory Preset Modes). Restart the computer so
that the new settings take effect.
Out of Range. Set
Monitor to 1920 × 1200
@ 60Hz is displayed on
screen. (LP2465 24" model)
Video resolution and/or refresh
rate are set higher than what the
monitor supports.
Restart the computer and enter Safe Mode. Change the
settings to a supported setting (see Table B-6 LP2465
Model Factory Preset Modes). Restart the computer so
that the new settings take effect.
Solving Common Problems 33

HP LP1965 Specifications

General

Operating temperature (T-T)	5 - 35 °C
Non-operating relative humidity (non-condensing)	5 - 90 %
Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-4 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
3D	No
HD type	-
Panel type	TFT
Pixel pitch	0.294 x 0.294 mm
Aspect ratio	4:3
Response time	6 ms
Display surface	Matt
Display diagonal	19 \
Display resolution	1280 x 1024 pixels
Display technology	LCD
Vertical scan range	48 - 76 Hz
Horizontal scan range	24 - 83 kHz
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 24-83 kHz, Vertical frequency: 48-76 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	1280 x 1024 (SXGA)
UNSPSC-code	43211902
Audio included	No audio included No audio included at platform level
Rear ports note	4 USB 2.0
Native resolution	SXGA (1280x1024) pixels
Security features	Kensington Lock-ready
Weight (imperial)	15.6 lb lbs
Power requirements	Auto-ranging, 90 to 265 VAC, Internal power supply, 50 to 60 Hz (built-in power supply)
Recommended resolution	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75
Display resolution at frequency	Preset VESA Graphic Modes (non-interlaced): 1280 x 1024 @ 60 and 75 Hz, 1024 x 768 @ 60, 70 and 75 Hz, 1152 x 870 @ 75 Hz (Mac), 1152 x 900 @ 76 Hz (Sun), 832 x 624 @ 75 Hz (Mac), 800 x 600 @ 60, 72 and 75 Hz, 720 x 400 @ 70 Hz, 640 x 480 @ 60, 72 and 75 Hz
Dimensions (W x D x H) (imperial)	15.9 x 8.78 x 18.79 \
Product dimensions (without stand, imperial)	15.9 x 2.4 x 12.96 \
Product color	Black, Silver
Country of origin	China
AC input voltage	90 - 265 V
AC input frequency	50 - 60 Hz
Power consumption (max)	55 W
Power consumption (standby)	2 W
Power consumption (typical)	35 W
I/O ports	One upstream, four downstream ports (cable included)
USB hub version	2.0
DVI-D ports quantity	0
DVI-I ports quantity	2
USB Type-A downstream ports quantity	3
Cables included	AC, DVI
Interface adapters included	DVI-I female - VGA male

Weight and Dimensions

Depth (with stand)	222.9 mm
Width (with stand)	403.9 mm
Height (with stand)	377.2 mm
Weight (with stand)	7060 g
Depth (without stand)	61 mm
Height (without stand)	329.1 mm
Weight (without stand)	4190 g
