HP M24fwa User Manual

17
M27fwa
This procedure includes HDMI and VGA connectors.
The connectors are on the main board (board part number R352726520150
The connectors identifiers are as follows:
Connector
Location
HDMI 1/2
P200/P300
VGA
P100
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly
on page 12.
HDMI connector P200/P300
Repair the HDMI connector:
1) Use a soldering iron and a desoldering pump to remove as much solder as possible from the pin.
M24fwa
P300
P200
P100
P200
P100

HP M24fwa Specifications

General

Color	ceramic white, white
Screen Type	lcd
Tiltable	yes
Touch Screen	no
Webcam	no
OS Compatibility	not applicable
Screen Size	23.8 inches
Panel Type	ips
Aspect Ratio	16:9
Resolution	1920 x 1080
Native Resolution	1920 x 1080
Refresh Rate	75hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	5 milliseconds
Brightness	300 candela per square meter
Contrast Ratio	1000:1
Synchronization	freesync (amd adaptive sync), not applicable
Horizontal Scan Rate	86 kilohertz
HDR	no
Built-In Speakers	yes
HDMI Ports	1
USB Type B Ports	0
Display Port Inputs	0
Mini Display Port	0
VGA Ports	1
DVI	0
Thunderbolt Ports	0
Voice Assistant	not applicable
Height with Stand	12.42 inches
Width with Stand	21.09 inches
Depth without Stand	6.97 inches
Height without Stand	15.62 inches
Net Weight without Stand	5.5 pounds
