6
Rear components
To identify the components on the rear of the monitor, use this illustration and table.
Table 1-1: Rear components and their descriptions
Component
Function
1
Power connector
Connects an power cord..
2
DisplayPort IN port
Connects a DisplayPort cable from the source
device to the monitor
3
HDMI Port
Connects an HDMI cable from the source
device to the monitor
4
USB Type C
Connects a USB TypeC
cable from the source device to the monitor.
Serves as a single connection when docking an
HP notebook.
5.
USB ports (2)
Connects a USB device, provides high speed
data transfer, and charges small devices

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP M27 and is the answer not in the manual?

HP M27 Specifications

General IconGeneral
Color gamut99 %
Pixel pitch0.3114 x 0.3114 mm
Screen shapeFlat
Pixel density82 ppi
Display diagonal27 \
Surface hardness3H
Anti-glare screenYes
Maximum refresh rate75 Hz
Contrast ratio (typical)1000:1
Display diagonal (metric)68.58 cm
Digital vertical frequency48 - 75 Hz
Digital horizontal frequency30 - 85 kHz
Display brightness (typical)300 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version1.4
DisplayPort version1.2
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)130 W
Power consumption (standby)0.5 W
Power consumption (typical)20 W
Operating temperature (T-T)5 - 35 °C
Package depth211.4 mm
Package height544 mm
Package weight11300 g
Height adjustment100 mm
Panel mounting interface100 x 100 mm
CertificationArgentina S-Mark; BIS; CB; CCC; CE; CEL; CEL Grade 1; C-Tick; cTUVus; ENERGY STAR®; EPA; EUP Lot-5; EUP Lot-6; FCC; GS Mark; ICES; ISO 9241-307; KC/KCC; NOM; NOM (Mexico); RCM; UL/CSA-NTRL/ETL-NRTL Mark; VCCI; WEEE; EUP Lot-26; California Energy Commission (CEC); South Africa Energy; eStandby; Mexico LASE form; ICE; KES; PSE EAC; India BIS
Product colorBlack, Silver
Country of originChina
Market positioningHome
Megapixel5 MP
RMS rated power4 W
Number of speakers2
Sustainability certificatesENERGY STAR
Depth48.2 mm
Height413 mm
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)54.4 mm
Width (with stand)61.2 mm
Height (with stand)21.14 mm
Weight (with stand)7300 g
Depth (without stand)4.82 mm
Width (without stand)612 mm
Height (without stand)41.3 mm
